Dyaco RT86 - Y75 - A Electrical Configuration; Description; RT86-Y75 Treadmill Components

S
S
e
e
r
r
v
v
i
i
c
c
e
e
M
M
a
a
n
n
u
u
a
a
l
l
D
D
e
e
s
s
c
c
r
r
i
i
p
p
t
t
i
i
o
o
n
n
D
D
e
e
s
s
c
c
r
r
i
i
p
p
t
t
i
i
o
o
n
n
4
4
DESCRIPTION
A ELECTRICAL CONFIGURATION
Note: Electrical servicing of this treadmill is limited to board
level replacement.
1. RT86-Y75 TREADMILL COMPONENTS
a) Safety Key:
In dangerous condition, please pull safety key away which is
red. At the some time, the treadmill will be stop.
b) Console:
Interface that control all functions of the treadmill.
c) Main controller:
A circuit board that incorporates the DC power supply and
takes input from the console and sends out appropriate
voltages that control the treadmill functions.
d) Treadmill motor:
This is a variable speed, to control D.C. motor（90 voltage）
that powers the main running belt.
e) Incline motor:
An AC reversing motor that sets the incline of the treadmill.
