14
CLEANING
Burner Assembly
Removing The Burner Assembly
1. Make sure the control knob is in the OFF
position, gas supply valve is closed, and gas
regulator is disconnected from the gas supply.
2. Remove all M6x12 screws from rebox assembly
and from the bottom panel as illustrated in
Figure 1..
3. Detach ignition wire from electrode as illustrated
in Figure 2 and slide burner out from rebox.
Figure 1
Figure 2
CAUTION
Ensure the griddle is cool before cleaning and conducting maintenance and with the gas
supply turned off at the propane cylinder.
