6
ASSEMBLY INSTRUCTIONS
1. First, remove pre-assembled four
M6x12 screws from rebox assembly (A), then
attach leg (D) to rebox assembly (A) used
removed screws.
2. Assemble the knob (C) and grease cup (B).
2
1
D
D
A
ACB
