ASSEMBLY INSTRUCTIONS
6
6.Attach reflector spacers (FF) and three washers Ø8
(GG) to screen cover on the head assembly (C).
Tighten the reflector spacers(FF). Unscrew four stainless
steel bolts (DD).
7. Load head assembly (C) by inserting hose into post (E).
Control knob should be above decal on post (E).
Attach head assembly (C) to post (E), and loosely install
four stainless steel bolts M6X10(DD). Tighten bolts
securely.
7
FF
GG
FF
GG
x 3
Reflector Spacer
x 3
Washer Φ8
Hardware Used
x 1
LL
Wrench
x 1
LL
Wrench
Hardware Used
DD
x 4
Stainless steel
bolt M6X10
C
DD
E
DD
C
