46(J)
Connect
a
1"
bare
wire from
eyelet
#23
on
PC-8
(8)
to
eyelet
B
(S).
This
jumper
should
b<'
k<,pt
close to
tJw
board,
but
it
must
not
touch ;'ldjacent
circuitry.
47(~'
)
Connect
one
end
of a
3"
red wire to
eyelet
#30
on
the
top
of
PC-8
(S).
"Tin"
the
wire
with
solder
first,
and
then
insert
the
wire
{rom
above
as
the
eye-
let
is heal,ed
(rom
below,
48(
J)
Connect
one
end
of a 2V2" rcd wire to
eyelet
#2B
on
the
top
of
PC8
(S),
49
(,j)
Connect
one
end
of a 3"
gn'l'n
wire to
eyelet
#2G
on
the
lop
of
PC-S
(,S),
50(
,J)
Slide
the
tuning
dial
indicator
disc
fully
onto
the
tuning
capacitor
shaft,
The
hub
goes on
the
shaft
first,
and
its
flat
side
engages
the
flat
portion
of
the
shaft,
Be
sure
the
disc
is
pushed
on
to
the
full
depth
of
the
flat.
51
(-,/) Te'lllporal'ily
dl~mount
the' volume'
control
assembly
from
the
front
panel
and
set
it
to
one
sid(',
52
(,
)
Position
the
front
panel
sub-assemhly
adjacent
to
the
front
of
the
chassis.
Take
the
green
and
black
twisted
pair
of wire'S which
protrude
from
the
sm:lll
slot
in
the
chassis,
Connect
th('
black
wire to
pin
#4
of
V8
(8),
Connect
the
green
wire
to
pin
#5
of VS
(S).
53 (
~
)
Thrcnd
the
red
and
gn'l~n
wires from
pins
#6
and
#7
of VS
through
the
small
slot
in
the
front
of
the
chassis
and
through
grommet
#2.
54 (
~
Mount
the
front
panel to
the
chassis
usmg
three
sets
of
#4
hardware.
55(
>.5
Connect
the
black
wire from
pin
#3
of
socket
V8
to
cyeld
#25
on
top
of
PC-8
(S).
56(
!)
Connect
the
red wire from
eyelet
#30
to
pin
#2
of
socket
VS
(S),
Access to
pin
#2
can
be
gained
through
the
front
panel
cutout.
Position
this
wire
fiat
against
the
board,
and
over
to
the
front
panel.
57(
'I)
Connect
the
red
wire from
l~yelet
#2S
to
pin
#8
of
V8
(8).
58 (,
')
Position
the
gre~n
wire from
eyelet
#26
under
the
VS
mounting
bracket,
and
connect
it
to
pin
#9
of
VS
(S).
59 ( -,)
Connect
on~
end
of a
1112"
green wire to
eyelet
A
of
PC-S
on
the
top
of
the
board.
80lder
it
from
the
bottom
of
the
board.
60(
J)
Conneot
the
other
end
of
the
1
1
12"
green wire from
eyelet
A of
PC-S
to
the
top
of
eyelet
A
on
PC-7
(S).
61 ( )
Slide
the
%"
lockwasher
on
the
volume
control
shaft,
and
mount
the
assembly
on
the
front
panel,
positioning
the
lugs
as
in
the
pictorial,
but
do
not
tighten
the
%" nut.
Be
careful
of
the
disc
capacitors
on
PC-S,
62
(.A
Connect
the
short
black
wire from lug # 1 of
the
volume
control
to
eyelet
# 37 on
PC-S
(S),
A quan-
tity
of
solder
should
be
applied
to ey<'!et
#37
on
the
copper
side
of
the
bO:lrd,
and
flowed over to
the
chassis
to
make
a good
ground
contact
to thl'
chassis.
63(,
)
Twist
togeth<'f
the
remammg
black wire from lug
#4
of
the
control
and
the
green wire from lug
#5
of the controL
Connect
the
black wire to
eycJd
#S'l
on
top
of
the
PC-12
boa
I'd
(S).
Connl'ct
the
greeIl
I wire to
cyt'let
#
SO
(S).
64 ( " )
Take
the
red
and
black
twisted
pair
of wires which
are
connected
to lugs # 1
and
#2
of
the
control.
Connect
the
black wire to
eyelet
# 84
(8).
Connect
the
rpd wire to
eyelet
#86
(S).
Position
the
rcd-
black
and
green-black
pairs
of
leads
from
this
and
from
the
prec~ding
step
exactly
as
shown in
the
diagram,
around
V71,
and
away
from 1'73.
Keep
them
clear
of
the
board.
I
65
(I)
Take
the
black,
red
and
green
twisted
group
of
wires from
the
switch
on
the
volume
control
as-
sembly,
and
connect
the
black
wire to
eyelet
#77
(S).
Connect
the
green
wire to
eyelet
# 78
(S).
Connect
the
red
wire to
eyelet
#76
(S),
66(
v)
Thread
the
twisted
pair
of
red wires from
the
switch
through
the
slot
in
the
chassis
adjacent
to
PEC-I.
On
the
underside
of
the
board,
connect
these wires
to
lugs
#2
and
#3
of
the
transformer
T73,
as indi-
cated
in
the
diagram.
Wrap
each
wire
around
the
lug
and
solder
it
to
the
lug
and
to
the
copper
on
the
board.
Note
that
this
transformer
has
5
connecting
lugs
positioned
around
the
access hole.
Be
sure
that
the
red
wires
are
soldered
to
the
proper
points.
Either
wire
may
connect
to
either
lug.
Be
sure
that
bare
wire
does
not
contact
adjacent
circuit
points.
67(
J)
Observe the
red
and
the
green wires
protruding
through
grommet
#2.
Connect
the
red wire to eye-
let
#79
on
PC-12
(8).
Connect
th0.
gr0.cn wire to
eyelet
#75
(8).
This
gwen
wire
may
appear
long,
but
the
extra
length
is used in
the
alignment
procedure.
68(
J)
Mount
the
discriminator
transformer
T5
(432002).
This
transfornH'r has five
connecting
lugs
and
two
mounting
tabs,
It
can
be mount(,d in only
one
po-
sition.
Press
it
firmly to
the
board
and
solder
both
mounting
tabs
and
the
five connl:cting lugs. Do
not
use
excessivp
heat
on
the
five lugs. Avoid
using
too
much
solder, which
could
flow into
the
transformer
and
damage
it.
69 (
t/)
Insert
the
end
of
the
line
cord
through
grommet
#3
in
the
rear
of
the
chassis
and
pull
through
about
6
inches.
Tie
a Imot 4
inches
from
the
end,
and
pull
the
line
cord
back
so
that
the
knot
seats
against
the
grommet.
Split
the
two
conductors
of
the
line
cord
down
to
the
knot.
Connect
one
of
the
two
leads
to
lug
# 1 of
the
fuse
holder
(S-2).
Connect
the
other
lead
to
lug
#5
of
the
five
lug
terminal
strip
(S-2).
Now
check
to
see
that
the
black
twisted
pair,
of
which
one
wire
connects
to
lug
#5,
is
positioned
away
from PC-12.
