dynabook S Series - Page 39

1 Hardware Overview
dynabook PORTEGE A30-E/TECRA A30-G,-J/dynabook S Series Maintenance Manual (960-931) [CONFIDENTIAL] 1-25
1.8 AC Adapter
The AC adapter is used to charge the battery. This model corresponds to USB-PD also.
The following table lists the AC adapter specifications.
Table 1-9 AC adapter specifications
Item Specifications
Chicony Liteon
G71C000GZ610 (2-pin) G71C000GX610 (2-pin)
Power
45W
Input voltage
100V/240V
Input frequency
50Hz to 60Hz
Output voltage
19V±5% 19V±5%
Output current
2.37A (Peak 2.89A) 2.37A (Peak 2.89A)
Dimension (mm)
36(W) x 85(L) x 26.3(H) (Typ.)
36.5±1(W) x 87±1(L) x 25.4
±1(H)
Cable length
(mm)
1800±50
Item Specifications
Chicony
G71C000H0510 (3-pin)
Power
45W
Input voltage
100V/240V
Input frequency
50Hz to 60Hz
Output voltage
19V±5%
Output current
2.37A (Peak 2.89A)
Dimension (mm)
36(W) x 85(L) x 26.3(H) (Typ.)
Cable length
(mm)
1800(±50)
