dynabook Satellite C40-J - Installing the LCD Module Mask

NOTE: When installing the LCD Module Mask, ensure there is no gap between the
LCD Module Mask and the LCD module cover.
NOTE: Do not lose the Camera Shutter.
Installing the LCD Module Mask
Install the LCD Module Mask according to the following procedures and Figure 4-
27 & 4-28.
1. Install the LCD Module Mask and follow step 3, 2 & 1 to press & lock the latches.
2. Securing the LCD Module Mask with four M2.0x3.0x4.5 black Phillips head screw.
3. Install
4. 4 rubber foot pads Install four plastic pads.
