NOTE:
Touch SKU will provide the FRU parts as LCD Module Assembly.
This chapter only for Non-Touch SKU.
NOTE: ICs are fragile. Use extreme care not to apply pressure to the ICs along the
edges of the LCD module.
NOTE: Dispose of used LCD Panel (fluorescent (FL) tubes) as required by local
ordinances or regulations.
NOTE: The LCD cable must be carefully peeled away before disconnecting it from the
module.
4.12
LCD Panel
Removing the LCD Panel
Remove the LCD Panel according to the following procedures and Figures 4-29
&4- 30.
1.
Follow the Figure 4-29 direction 1 to lift up LCD panel.
2.
Carefully tilt the LCD module toward you.
3.
Turn the LCD upside down. Be sure to place it on a cushioned surface
such as a foam pad.
4.
Remove the tape and LCD cable connector. Then disconnect the LCD
cable as Figure 4-30 shown.
