REFER
TO
PICTORIAL
DIAGRAM
;:r3.
26 ( )
Connect
one nd of the 6S00-ohm
(bi
ue. gray,
red).
1-watt resistor to lug
;;2
(square
symbol)
of
the
filter capacitor.
Connect
the
other
end
to lug
#3
(triangle
symbol)
of
the
capacitor.
The
resistor leads
should
be
cut
to
permit
mounting
exactly
as
is shown
in
the
diagram.
27( )
Connect
one
end
of the 50-ohm,
5-watt
resistor to
lug
# 1
(curved
line
symbol)
of
the
filter capacitor.
Connect
the
other
end
to lug
:#I
2
(square
symbol)
of the
capacitor
(S).
Check to be
sure
that
all
four
of the connections
at
lug
#2
have been
solden~d,
and
that
excess wire has been
trimmed
away,
and
cannot
touch
the chassis
or
adjacent
lugs.
2S( )
Connect
one
end
of the 95-ohm,
5-watt
resistor to lug
#4
(no
symbol) of
the
filter
capacitor.
Connect
the
other
end
to chassis-mounting lug B of
the
capacitor.
29 ( )
Connect
one
end
of a 5/' wire to
chassis-mounting
lug B of the filter
capacitor
(S).
Connect
the
other
end
to lug
#3
of the 5-lug
terminal
strip
(S).
30( )
The
silicon rectifier diodes
supplied
with the
kit
may
be
of
any
of the
three
types shown in
the
illustration;
although
differing in
external
appearance,
the
three
types
are
electrically
equivalent.
Connect
the
CATHODE
lead of one
of
the
rectifier diodes to lug # 1
(curved
line
symbol)
of
the
filter
capacitor.
Connect
the
ANODE
lead
to lug
-#
2 of
the
5-lug
terminal
strip
r
8).
IMPORTANT:
Arrange
the
-·E--
diode leads
exactly
as
shown
in
the
pictorial
diagram.
When
soldering,
hold a pliers
on
the
lead
between
the
diode
body
and
the
solder
connection
to avoid
application
of excessive
heat
to the diode.
31 ( )
Connect
the
CATHODE
lead of
the
other
rectifier
diode
to lug # 1
(curved
line
symbol)
of the filter
capacitor
(S).
Connect
the
other
lead to
lug
# 1 of
the
5-lug terminal
strip
(8).
Observe
the
same
pre-
cautions
when
soldering
as
in
the
preceding
step.
32 ( )
Connect
one
end
of a
4"
wire to lug C of
the
RIGHT
3-screw
terminal
strip
(8).
COlUlect
the
other
end
to
chassis-mounting
lug A of
the
filter
capacitor.
33(
)
Connect
one
end
of a
9"
wire to
lug
C of
the
LEFT
3-screw terminal
strip
(S).
COlUlect
the
other
end
to
chassis-mounting
lug
A of
the
filter
capacitor
(S)
.
34 ( )
Connect
one
end
of a 4" wire to
lug
# 3
(triangle
symbol)
of the filter
capacitor.
Connect
the
other
end
to
eyelet
#7
of the
RIGHT
circuit
board
(8).
NOTE:
Before
making
a
connection
to
an
eye-
let
on
the
circuit
board,
tin
the
end
of
the
wire
by
heating
it
with
the
soldering
iron
and
touch-
ing
solder
to it.
The
wire
end
is
tinned
when
the
solder
melts
and
runs
onto
the wire.
The
eyelets
on
the
board
already
have
solder
in
them.
To
solder
to
the
eyelet,
heat
it
with
the
soldering iron
and
insert
the
end
of the wire
when
the
solder
in
the
eyelet
flows.
Remove
the
iron
and
hold
the
wire in
place
until
the
solder
hardens.
35 ( )
Connect
one
end
of a
5"
wire to
lug
#4
(no
symbol)
of th filter
capacitor.
Connect
the
other
end
to pin
;;3 of V-5
on
the
RIGHT
circuit
board.
36 ( )
Prepare
a 13/1" piece of wire
by
stripping
112"
of insu-
lation from one
end,
and
II," from
the
other
end.
8
Push
the longer
bare
end
through
pin
=3
of V-6 on
the
RIGHT
circuit
board
(8),
and
bend
it
around
to conn
ct
to
pin
;:;4 of V
-6
also.
Connect
the
other
nd
to pin # 3 of V-5
(8).
37 ( )
Connect
one
end
of a 4
V2"
wire to
eyelet
#4
of the
RIGHT
circuit
board
(8).
Connect
the
other
end
to
eyelet
#
10
(8).
3S(
)
Twist
together
a 2
1
/
2
"
and
a
4"
wire so
that
one pair
of
ends
is
even.
Connect
the
matching
ends
to pins
#4
and
¢j:!)
of
V-;)
on the
RIGHT
circuit board.
Connect
the
shorter
of the remaining
ends
to
eyelet
#5
(S),
and
the
longer remaining end
toeyel
t
=3
(8)
.
39 ( )
Twist
together
a
pair
of 2
1
/
2
" wires.
Connect
one
pair
of
ends
to
pin
#4
(8)
and
pin
:;:S
(8)
of
V-S
on
the
RIGHT
circuit
board.
Connect
the
other
ends
to
pin
#4
(8)
and
pin
#5
(8)
of V-6.
40(
Connect
one
end
of a
7"
wire to lug
16
of the
RIGHT
3-screw
terminal
strip
(S).
Connect
the
other
end
to
eyelet
#6
of
the
RIGHT
circuit
board
(S).
41 ( )
Connect
one
end
of a 1
1
1i" wire to pin # 9 of V-6
on
the
RIGHT
circuit
board
(8).
Connect
the
other
end
to
eyelet
# 11 (S L
42 ( )
Connect
one
end
of a
1"
bare
wire to pin # 2 of V-6
on
the
RIGHT
circuit
board
(8).
Connect
the
other
end
to
eyelet
#9
(S).
43(
)
Connect
one
end
of a 1"
bare
wire to pin
#2
of V-5
on the
RIGHT
circuit
board
(S).
COImect the
other
end
to
eyelet
#8
(S).
44 ( )
Connect
one
end
of a
1"
wire to the long lug of the
RIGHT
input
socket
(8).
Connect
the
other
end
to
eyelet
#1
(S).
45 ( )
Connect
one
end
of a 1
1
/
2
"
wire to the
short
lug of
the
RIGHT
input
socket
(S).
COllilect the
other
end
to
eyelet
#2
(S).
46(
)
The
next
group
of
steps
are
performed
on
the
LEFT
circuit
board.
Connect
one
end
of a 12" wire to
lug
# 3
(triangle
symbol)
of the filter
capacitor
(8).
COlUlect
the
other
end
to
eyelet
#7
of the
LEFT
circuit
board
(S).
47( )
Connect
one
end
of a 10" wire to lug
#4
(no
sym-
bol)
of
the
filter
capacitor
(S).
Connect
the
other
e~d
to
pin
#3
of V-2 on the
LEFT
circuit board.
48(
)
8trip
112"
of
insulation
from
one
end
of a
1%"
piece
of
wire;
strip
about
VI"
from the
other
end.
Push
the
longer
bare
end
through
pin
#3
of V-3
on
the
LEIT
circuit
board
(S),
and
then
bend
it back to
connect
it
to
pin
#4
of V
-3.
Connect
the
other
nd
to pin
#3
of V-2
(S).
49 ( )
Connect
one
end
of a 4Ih" wire to
eyelet
#4
of
the
LEFT
circuit
board
(8).
Connect
the
other
end
to
eyelet
#10
(8).
50 ( )
Twist
together
a
21;2"
and
a
4/1
wire, so
that
one
pair
of
ends
is even.
Connect
the
matching
ends
to
pins
#4
and
#5
of V-2
on
the
LEFT
circuit
board. Con-
nect
the
shorter
of
the
remaining
ends
to
eyelet
# 5
(8),
and
the
longer
end
to
eyelet
#3
(S).
51
( )
Twist
a
pair
of 2
1
12/1
wires together.
Connect
one
pair
of
ends
to
pin
#4
(8)
and
pin
#5
(8)
of V-2 on
the
LEFT
circuit
board,
and
the
other
ends
to
pin
#4
(S)
and
pin
#5
(S)
of V-3.
52(
)
Connect
one
end
of a 5" wire to
lug
16 of
the
LEFT
3-screw
terminal
strip
(S).
Connect
the
other
end
to
yelet
#6
of
the
LEFT
circuit
board
(S).
