3. Installation
Please read the instructions provided in this chapter thoroughly before installing
the IP Bullet Camera.
3.1 Ceiling / Wall Mounting
The IR Bullet IP Camera can be installed directly on a wall or ceiling with the
integrated 2-axis adjustable Bracket Mount. Please note that the wall or ceiling
must have enough strength to support the IP Camera.
Follow the steps below to install the IP Camera:
Step 1:
Unpack the IR Bullet IP Camera package and take out the IP Camera.
Step 2:
Connect the power / Ethernet / alarm / audio wires from ceiling or wall to the
corresponding connectors of the camera’s All-in-one Cable.
Step 3:
Fix the IP Camera’s Bracket on the
ceiling / wall with three supplied self
tapping screws.
Step 4:
Loosen the screw indicated in the
figure, and adjust the camera to a
desired position, and tighten the
screw to secure the camera.
