Dynalco SST2000A - Page 23

23
Calibrating the Speed Switch
Freq. Range
(in kHz)
Switch A ON
Positions
Freq. Range
(in Hz)
0.08 - 0.10 1, 8 80 - 100
0.10 - 0.13 2, 8 100 - 130
0.13 - 0.17 3, 8 130 - 170
0.17 - 0.22 4, 8 170 - 220
0.22 – 0.30 5, 8 220 - 300
0.30 - 0.38 6, 8 300 - 380
0.38 – 0.50 7, 8 380 - 500
0.48 – 0.63 7, 2, 8 480 - 630
0.63 – 0.83 1, 4, 7, 8 630 - 830
0.83 – 1.09 1, 2, 3, 5, 6, 8 830 - 1,090
0.86 – 1.12 1 860 - 1,120
1.10 – 1.40 2 1,100 - 1,400
1.40 – 1.90 3 1,400 - 1,900
1.90 – 2.50 4 1,900 - 2,500
2.50 – 3.20 5 2,500 - 3,200
3.20 – 4.20 6 3,200 - 4,200
4.20 – 5.50 7 4,200 - 5,500
5.30 – 6.90 7, 2 5,300 - 6,900
6.90 – 9.10 1, 4, 7 6,900 - 9,100
9.10 – 12.0 1, 2, 3, 5, 6 9,100 - 12,000
12.0 – 15.5 2, 3, 4, 6, 7 12,000 - 15,500
15.1 – 20.0 1, 2, 3, 4, 5, 6, 7 15,100 - 20,000
Table 4-1 Table of
full-scale frequency and
the corresponding switch
“A” ON settings.
