3.13 7.9
7.75 19.7
8.25
21
1.81 4.6
3.75 9.5
4X
.25 0.64
DIMENSIONS IN INCHES[CM]
Physical Dimensions
Getting Started
3
Fig. 1-1 Top and side views of the SST-2000A/H.
Dimensions in inches and (centimeters).
Special explosion proof housings kits (complete
with mounting hardware) are also available.
See XP rated housings on page 6.
