GBK60348: Issue 3 47
The System Backup Mirror does not look at remote compatibility and will show the
SBM Selection Sequence, even if a DX2-REM550 has been replaced with a DX2-
REM421, for example. Once an incompatible program has been loaded into the
Remote, the system will show Flash Code 12 to indicate that the Remote contains a
program that is not compatible. Reprogram the DX System with the Wizard to clear
this fault.
If the Wizard tries to write an incompatible program to a Remote, the Wizard will give
a fault message and the program will not be written. Select another program, or
convert the current program to the correct Remote type with:
Tools Change Module Type
In the Module field, select DX UCM Master Remote
In the Convert to field, select the correct Remote type
Click Convert
It will now be possible to write the program to the Remote.
4.1.4 Replacing modules other than a DX2 Master Remote or DX2 Power
Module.
When replacing modules on an existing chair, you should always consult the relevant
manual of the module that you are replacing. The following information is provided as
a brief overview, and does not replace the more detailed information in the relevant
manual.
The following modules do not hold any programming information and can be
replaced without the need to re-programme:
o DX-CLAM
o DX-TAM
o DX-RJM
o DX-ACU
o DX-ECU
o DX-ARC
o DX-LM
o iPortal
The following modules will download programming information from the Master
Remote, as such they do not need to be re-programmed:
o DX-SLM
o DX2-ACT
The following modules store some parameters in the module itself and will need to
have their programming checked, and, if necessary, be re-programmed via the
Wizard when replaced:
o DX-IRIS2
o DX-5SW secondary remote
