Dynapac BM Series - Page 16

INSTRUCTIONS MANUAL – BR-BM
File: 4700367205_ENG_NO.doc Page 16 / 25
Qty.
Ref Description Part
number
BR66

BR66 BR66 BR67 BR67 BR67
230V 400V 230V 400V
1 Beam cpl. 4723640201 2 2 2 - - -
Beam cpl. 4723640202 - - - 2 2 2
2 Vibrator holder 4700236485 1 1 1 1 1 1
3 Handle 4700236407 4 4 4 4 4 4
4 Bolt 4700236289 4 4 4 4 4 4
5 Tube 4700236290 4 4 4 4 4 4
6 Washer 4700236317 20 20 20 20 20 20
7 Cap nut 4700581010 20 20 20 20 20 20
8 Washer 4700236322 4 4 4 4 4 4
9 Washer 4700615046 4 4 4 4 4 4
10 Attachment 4700236408 4 4 4 4 4 4
12 Screw 4700500082 4 4 4 4 4 4
13 Screw 4700500076 8 8 8 8 8 8
14 Screw 4700500103 2 2 2 2 2 2
15 Nut 4700570007 2 2 2 2 2 2
16 Plug 4700367139 2 1 1 2 1 1
17 Switch breaker 4700929182 1 - 1 1 - 1
Switch breaker
(230V)
4700912486 - 1 - - 1 -
18 Attachment 4700236276 2 2 2 2 2 2
19 Flat bar 4700236277 2 2 2 2 2 2
20 Plate 4700236467 2 2 2 2 2 2
21 Rubber plate 4700236469 1 1 1 1 1 1
22 Clamp 4700921036 4 4 4 5 5 5
23 Screw 4700500053 4 4 4 4 4 4
24 Screw 4700500021 10 10 10 10 10 10
25 Nut 4700586003 10 10 10 10 10 10
26 Screw 4700533060 4 4 4 5 5 5
27 Screw 4700533032 6 6 6 6 6 6
28 Nut 4700586001 6 6 6 6 6 6
29 Washer 4700600004 4 4 4 3 3 3
30 Plastic pipe 4700906010 2.80m 2.80m 2.80m 3.35m 3.35m 3.35m
31 Plug 4700940086 1 - 1 1 - 1
31 Plug 4700940093 - 1 - - 1 -
32 Nut 4700570004 4 4 4 5 5 5
33 Motor vibrator 4700185579 - 1 1 - 1 1
34 Cable 4700901025 - 3.6m 3.6m - 4.35m 4.35m
35 Screw 4700500267 - 4 4 - 4 4
36 Washer 4700600267 - 8 8 - 8 8
37 Nut 4700586019 - 4 4 - 4 4
38 Sealing sleeve
(230V)
4700367138 - 1 - - 1 -
Sealing sleeve
(400V)
4700367138 - - 1 - - 1
39 Handle cpl. 4700236475 2 2 2 2 2 2
40 Holder 4700367459 1 1 1 1 1 1
41 Screw 4700533025 4 4 4 4 4 4
