INSTRUCTIONS MANUAL – BR-BM
File: 4700367205_ENG_NO.doc Page 7 / 25
TECHNICAL DATA
Vibrating
beams
Vibrator
type
Eccentric
setting
Rating
W
Length
m
Width
m
Weight
kg
Noise
level**
Weighted
eff. accel.***
BM 61 BE 10 Without 2240 3.25 0.45 48 * 93.00 2.55
BM 62 BE 10 Without 2240 4.25 0.45 73 * 93.00 2.00
BM 63 BE 10 Without 2240 5.25 0.45 83 * 93.00 1.80
BM 64 BE 10 Without 2240 6.25 0.45 95 * 93.00 1.60
BR 61 ER 505 3 750 3.25 0.45 76 76.00 2.25
BR 62 ER 505 3 750 4.25 0.45 100 76.00 1.71
BR 63 ER 505 4 750 5.25 0.45 110 76.50 2.14
BR 64 ER 505 4 750 6.25 0.45 118 77.00 2.00
BR 66 ER 505 4 750 7.25 0.45 163 77.00 1.45
BR 67 ER 505 5 750 8.25 0.45 174 79.00 1.20
BR 68 ER 505 6 750 10.50 0.45 212 79.50 1.10
* Weights without BE10.
** Noise level dB(A) measured at 1m from the beam equipped with BE10 or with ER505, according to ISO
6081.
*** Weighted effective acceleration measured on the operating handle (m/s
2
), according to ISO 5349.
IMPORTANT
The above information is a general description only, is not guaranteed and contains no warranties of any
kind
OPERATING INSTRUCTIONS
ELECTRIC
VIBRATOR
ER
505
The electric vibrator is started by means of the switch which is mounted on a rubber block between the
beams.
The direction of movement of the beam can be changed by turning the switch knob to the opposite position.
For maintenance operations, voltage changes and eccentric settings refer to the ER 505 instruction provided.
PETROL
ENGINE
VIBRATOR
BE
10
For starting, stopping and maintenance operations refer to the instruction book provided.
SCREEDING
As soon as the vibrations are started the beam must be set in motion at a uniform speed of 0.5 -1 m/mn.
To avoid impressions in the concrete the beam must not be stopped while screeding is in progress.
Keep the underside of the beam horizontal to achieve the full effect of the vibration.
