Dynaudio 18S Instructions

Once installed and congured, your
18S should require little attention other
than perhaps occasional volume control
adjustment to suit different types of
programme material.
Cleaning your subwoofer
Bush the grille surfaces with a soft brush
and the cabinet surfaces with a clean
lint-free cloth. Do not use a vacuum
cleaner. If you wish to use a cleaning
agent, apply it to the cleaning cloth
and not directly to the subwoofer. Test
a small area rst, as some cleaning
products may damage some of the
surfaces.
Support
Should you require help or advice there
are a variety of support options for
Dynaudio products. These can be found
at dynaudio.com.
In use
26
Data 18 S
System Twin opposed driver, closed box, active DSP subwoofer
Frequency response 20Hz – 230Hz ±3dB
Inputs 2 x balanced XLR, 2 x unbalanced RCA phono
Max. input voltage 1.01Vrms @ +6 dB Sensitivity, 2.0Vrms @ 0 dB Sensitivity
4Vrms @ -6 dB Sensitivity, 10.1Vrms @ -14dB (LFE) Sensitivity
Outputs 2 x balanced XLR, 2 x unbalanced RCA phono
XLR output impedance Differential: 200Ω, Single-ended: 100Ω
Phono output impedance 100Ω
XLR Pin-out Pin 1: ground, Pin 2: signal +, Pin 3: Signal –
Auto ON/OFF Yes
Amplier power 500W
Power consumption (standby) <0.5W
Power consumption (max) 650W
Driver 2 x 24cm
Weight 20.5kg
45.2lb
Dimensions (W x H x D) 470 x 333 x 268mm
18.5 x 13.1 x 10.6in
In use
27
27
