Connecting the Esotec crossovers
Esotec / Esotar
2
Series 13
1. To connect the woofer
X Connect terminal 3 to the + terminal of the woofer.
X Connect terminal 4 to the – terminal of the woofer.
2. To connect the tweeter
The terminals 5, 6 and 7 offer the ability to fine-tune the sound level. This makes it possible to adjust the level
according to the placement of the speaker in the car and to your personal preference.
X Connect terminal 5 or 6 or 7 to the + terminal of the tweeter:
– just use one of the terminals 5, 6 or 7
– start with terminal 6 for the first setup
– use terminal 5 to increase the sound pressure level by 2 dB
– use terminal 7 to decrease the sound pressure level by 2 dB
X Connect terminal 8 to the – terminal of the tweeter.
3. To connect the power amplifier
X Connect terminal 1 to the + terminal of the power amplifier.
X Connect terminal 2 to the – terminal of the power amplifier.
