Dyness LV-Link A - Product Parameters

LV-Link A User Manual
©Dyness reserves the copyright of this document.
11
Battery 2 CAN Interface Definition
Foot position
Color
Definition
PIN1
Orange/white
Reserve
PIN2
Orange
Reserve
PIN3
Green/white
Reserve
PIN4
Blue
CAN2H
PIN5
Blue/white
CAN2L
PIN6
Green
Reserve
PIN7
Brown/white
Reserve
PIN8
Brown
Reserve
PIN9
Orange/white
Reserve
PIN10
Orange
Reserve
PIN11
Green/white
Reserve
PIN12
Blue
CAN2H
PIN13
Blue/white
CAN2L
PIN14
Green
Reserve
PIN15
Brown/white
Reserve
PIN16
Brown
Reserve
Tips: Please pay attention of the communication com definition of inverter, in order to
avoid voltage in the port to affect communication.
Product parameters
•
Operating voltage: 42V~60V
•
Operating temperature: -20
℃
~
＋
55
℃
•
Storage temperature: -10
℃
~+35
℃
• Relative humidity: 5% ~ 85%RH
• Elevation: no more than 4000m
