LV-Link A User Manual
©Dyness reserves the copyright of this document
6
2 Product Specification
Size and Weight
Table 2-1 LV-Link A Device size
Product
Nominal
Voltage
Dimension
Weight
LV-Link A
DC51.2V
135×82×36mm
1.5kg
Performance Parameter
Table 2-2 LV-Link A performance parameter
Item
Parameter value
Nominal Voltage(V)
51.2
Work Voltage Range(V)
42~60
Interface Definition
This section elaborates the interface functions of the front interface of the device.
Figure 2-1 The Sketch of Interface
