Dyson Ball Animal User Manual

Storing your machine
Carry your machine using the bin handle.
clik,
clik
Emptying your bin
Empty as soon as the dirt reaches the MAX level – don’t overfill. Using your
machine when the dirt is above the MAX line may affect the performance
and require more frequent filter washing.
Release the dirt
Hold your bin, with the bin base pointing down, over your trash can.
Firmly push the button on the bin handle, until the bin base opens.
Remove your bin
Turn off and unplug your machine.
Press the button on the bin handle to detach the bin from your machine.
Replace your bin
Push your handle into the upright position.
Push your handle firmly forward and listen for two clicks to lock in
upright position.
The stabiliser wheels will drop into position when the handle is locked
in the upright position.
Minimize dust contact
Cover your bin tightly in a dustproof bag while you empty. Remove
your bin carefully, seal the bag tightly and dispose.
Push the bin base up until it closes, clicking into place.
Position the bottom of your bin on your vacuum cleaner and then push
the top into your machine until it clicks securely into place.
There is a max
level located
approximately
half way up the
bin.
The bin release button is
located on the handle of
the bin.

Dyson Ball Animal Specifications

General

Product type	Upright vacuum
Dust capacity	1.1 L
Product color	Nickel, Silver
Country of origin	Malaysia
Dust container type	Bagless
Removable handheld vacuum	No
Package depth	926 mm
Package width	241 mm
Package height	294 mm
Package weight	9760 g
Cleaning type	Dry
Vacuum air filtering	-
Dirt separating method	Cyclonic
Cord length	9.5 m
Motor power	730 W
Power source	AC
Maximum input power	- W
Floor nozzle included	Yes
Vacuum brushes included	Parquet brush
Harmonized System (HS) code	8508110000

Weight and Dimensions

Depth	386 mm
Width	280 mm
Height	1058 mm
Weight	5600 g
