Assembling DCO7
1 Place the machine on its
side, remove the u-bend.
Slide hose into runners at
back of machine and
push down until it clicks.
Click the u-bend back
into place.
2 Press wand release button
and slide wand down into
hose.
DCO7
Lower cable winder
Airway inspection
(U-bend)
U-bend release clip
Hose
Wand cap
Upper cable winder
Wand
Wand release button
On/off switch
Filter housing
Valve release clips
Soleplate
Bin emptying trigger
Cyclone release catch
Shroud release catch
Shroud
Filter release catch
Ready-to-go hose release
Airway inspection valve
Stair tool
Crevice tool
Brush tool
1
2
Floortool
