DYU A1F - Page 2

Instrustions For Folding Ebike A1f
1-Shift Handle 10-Front Fork 19-Pedal
2-Dash Board 11-Tire 20-Crank
3-Brake Lever 12-Hub 21-Dental Plate
4-Handlebar 13-Disc Brake 22-Chain
5-Power Button 14-Reflector 23-Foot Push
6-Standpipe 15-Disc Brake 24-Rear Fender
7-Standpipe Folding Buckle 16-Front Fender 25-Rear Reflector
8-Headlight 17-Frame 26-Rear Light
9-Head Tube 18-Built-in Battery 27-Seat Tube
10-Front Fork 28-Seat
Note: Due to the company's product upgrade, some details of the product you get may be different from this
picture, but it does not affect your normal use.
配件清单图示
Foot Pedal×2 Charger×1 Manual×1 Warranty Card×1 Allen Key×1 15mm Hex Key×1
3. Fold the frame
2. Fold the riser
1. Put the seat to
the lowest level and
lock it
Folding Steps：
Install-Pedals：
Right foot pedal:
Rotate clockwise to install
Left foot pedal:
Rotate counterclockwise to
install
