3E-flite Hurricane 25e PNP/BNF Assembly Manual
EN
Table of Contents
Notice ................................................................... 2
Meaning of Special Language ................................. 2
Additional Safety Precautions and Warnings ........... 2
Introduction ........................................................... 2
Specifications ......................................................... 2
Using the Manual ................................................... 3
Contents of Kit/Parts Layout .................................... 3
Hardware/Accessory Sizes ..................................... 3
Recommended Radio Equipment ............................. 3
Replacement Power System ..................................... 3
Optional Accessories .............................................. 3
Optional Retracts ................................................... 3
Required Tools and Adhesives ................................. 4
Charging the Flight Battery - BNF ............................ 4
Propeller Removal and Installation - BNF/PNP ......... 5
Battery Installation - BNF/PNP ................................ 6
Transmitter and Receiver Binding - BNF ................... 7
Stabilizer Installation - BNF/PNP ............................. 7
Main Gear Installation - BNF/PNP .......................... 9
Optional Retract Installation - BNF/PNP ................ 10
Flap Linkage Installation - BNF/PNP ...................... 13
Joining the Wing Panels - BNF/PNP ..................... 14
Receiver Installation - PNP .................................... 16
Wing Installation - BNF/PNP ................................ 17
Center the Control Surfaces - BNF/PNP ................. 18
Center of Gravity ................................................. 19
Control Throws..................................................... 19
Preflight ............................................................... 20
Range Test Your Radio .......................................... 20
Daily Flight Checks ............................................... 21
Limited Warranty ................................................. 21
Compliance Information for the European Union ... 23
Academy of Model Aeronautics National
Model Aircraft Safety Code .......................... 24
Using the Manual
This manual is divided into sections to help make
assembly easier to understand and to provide breaks
betweeneachmajorsection.Inaddition,checkboxes
havebeenplacednexttoeachsteptokeeptrack
of its completion. Steps with a single circle () are
performed once, while steps with two or more circles
( ) indicate the step will require repeating, such as
for a right or left wing panel, two servos, etc.
Remember to take your time and follow the directions.
Contents of Kit/Parts Layout
Replacement Parts
EFL297501 Fuselage
EFL297502 Wing Set
EFL297503 Hatch
EFL597504 Tail Set
EFL297505 Radiator
EFL297506 Wing Mounts
EFL297507 Air Scoop
EFL297508 Antenna
EFL297509 Landing Gear Covers
EFL297510 Main Landing Gear with
2.75-inch (70mm) wheels
EFL297511 Lens Package
EFL297512 Hardware Pack
EFL297513 Landing Gear Mounts
EFL297514 Spinner, 2.50-in (63.5mm),
Black
EFL297515 Prop Hub
EFL297516 Tail wheel Assembly
EFL297517 Pushrod Set
EFL297518 Retract Cover Plate
EFLC3010 2–3S Li-Po Balancing Charger
EFLR7140 13 g Sub-Micro Servo
Hardware/Accessory Sizes
Main wheel diameter 3-in (76mm)
Tail wheel diameter 1.125-in (28mm)
Wingbolt   3mmx15mm
Recommended Radio Equipment
You will need a minimum 5-channel transmitter
for either the BNF or PNP versions of your model.
We recommend the crystal-free, interference-free
Spektrum
™
DX6i 2.4GHz DSMX
™
6-channel system.
If you are assembling the PNP version, you can choose
to purchase a complete radio system. If you are using
anexistingtransmitter,justpurchasethereceiver
separately.
Transmitter:
SPMR6610 DX6i DSMX 6CH Transmitter
Transmitter and Receiver:
SPM6610 DX6i DSMX 6CH Transmitter
with AR6210 Receiver
6-Channel Receiver:
SPMAR600 AR600 6-channel DSMX
receiver
Replacement Power System
EFLM7300 BL25 25 BL Outrunner
motor, 1000Kv
EFLB32003S30 3200mAh 3S 11.1V 30C Li-Po
EFLA1060 60-Amp Pro Switch-Mode
BEC ESC
EFLP117570 11.75x7propeller
Optional Accessories
EFLC3020 Celectra
™
200W DC Multi-
Chemistry Battery Charger
EFLA110 Power Meter
Optional Retracts
EFLG200 15–25 Electric Retracts
EFL297519 Retract Wire Struts
EFLG304 25–46AdjustableAxles(notfor
use with EFL297519)
