Current Draw
The chart below shows current draw with buss voltage at 13.8 volts (representing
normal buss voltage). If the buss voltage were to deteriorate (or go away), the curve
for the P-MAG would be much different. This chart is provided as an aid to builders
for planning their electrical loads under normal operating conditions.
E-MAG Ign. Current Map @ 13.8 nominal voltage
0.00
0.10
0.20
0.30
0.40
0.50
0.60
0.70
0.80
RPM
CURRENT
E-MAG model P-MAG model
E-MAG model
0.09 0.11 0.32 0.16 0.18 0.20 0.31 0.42 0.53 0.65 0.76
P-MAG model
0.09 0.11 0.32 0.16 0.17 0.23 0.30 0.15 0.02 0.00 0.00
0.00 0.00 200.00 300.00 400.00 500.00
1000.0
0
1500.0
0
2000.0
0
2500.0
0
3000.0
0
