CLASS 3400 METER
62-0391-03 4
1.0 INTRODUCTION
The E-Mon D-Mon® Class 3400 meter is a 3-element meter with communications. The
device is used to monitor electric power usage of individual loads after the utility meter
and store kW and kVAR data for automatic meter reading. The Class 3400 meter is
dual protocol capable and provides both RS485 and Ethernet communications.
Installation must only be performed by qualified personnel and in accordance with
these instructions and all applicable local and national electrical codes. E-Mon and its
representatives assume no responsibility for damages or injury resulting from the
improper installation of this meter.
Verify the input voltage rating and configuration on the unit panel label to ensure that it
is suitable for the intended electrical service. 3400 meters labeled for 120/208V service
MUST NOT be installed on service feeds of 277/480 volts or 347/600 and vice versa.
Verify that the Class 3400 meter’s current sensors are sized suitably for the load to be
monitored. Compare the color of the arrows on the current sensors to the chart below
to confirm the correct current sensor is being used.
Meter Labeled: Works On:
120V 120V, 1 Phase
120/240V 120/240V, 1 Phase
277V 277V, 1 Phase
208V 208V, 3 Phase
240V 240V, 3 Phase
400V 400V, 380V, 415V, 3 Phase
480V 480V, 3 Phase
600V 600V, 3 Phase
Sensor Arrow Color Code Sensor Rating
Brown 100 A
Red 200 A
Yellow 400 A
Black 800 A
Blue 1600 A
White/Black 3200 A
