Magnetic Track Setup
Description: To setup each magnetic stripe track parameters, changes will be effective
after scanner ACK response.
Scanner Response: ACK / NAK
Description
Field
Values allowed
Magnetic Track 1, 2, 3
Enable *
MAG1EN=1
Disable
MAG1EN=0
Enable *
MAG2EN=1
Disable
MAG2EN=0
Enable *
MAG3EN=1
Disable
MAG3EN=0
Table 2.9
LRC (Longitudinal Redundancy Check Character) Setup
Description: To setup track data with LRC (Check Character) to the host after
decoding. Changes will be effective after scanner ACK response. This command affects
all enabled tracks.
Scanner Response: ACK / NAK
Description
Field
Values allowed
LRC Character
Enable
MAGLRC=1
Disable *
MAGLRC=0
Table 2.10
Magnetic Raw Data Setup
Description: To setup raw data output to the host. Each 8-bit raw data is encoded into
two ASCII characters.
Example: 0000 0110 1011 0000
---- ---- ---- ----
"0" "6" "B" "0"
4 leading zeros + data + 4 trailing zeros
Hex representation: "06B0"
** The number of leading and trailing zeros may vary from time to time, depending on
the characteristic of the F2F chip.
Changes will be effective after scanner ACK response. This command affects all
enabled tracks.
Scanner Response: ACK / NAK
Description
Field
Values allowed
Raw Data Output
Enable
MAGRAW=1
Disable *
MAGRAW=0
Table 2.11
