E-Seek M210 - Page 4

Product Reference Guide
Parts of the Model M210/M260 2D
Bar Code and Magnetic Stripe
Reader
This page will provide an illustrated breakdown of the
Model M210/M260.
1. Cable Interface Connector
2. Power Supply Connector
3. Power On - Good Read LED
4. 2D Bar Code
5. Card Insertion Guide
6. Magnetic Stripe (M260 ONLY)
2
1
2
3
4
5
6
