REX12-Tx-E electronic circuit protector REX12-Tx-E electronic circuit protector
www.e-t-a.de
4
2045
4
type
REX12 Electronic circuit protector with PT connection technology
Mounting method
T rail mounting
Design
A 1 Load output terminal per channel, fixed current ratings xA
or xA/xA
Number of channels
1 1 channel (only 1 channel)
2 2 channels (only 2 channels)
Version
1 without physical isolation
Signal input
0 without signal input
Signal output
7 status output
Operating voltage
DC 24 V Current rating DC 24 V
Current ratings
1 A (only 1 channel)
2 A (only 1 channel)
3 A (only 1 channel)
4 A (only 1 channel)
6 A (only 1 channel)
8 A (only 1 channel)
10 A (only 1 channel)
1 A/1 A (only 2 channels)
2 A/2 A (only 2 channels)
3 A/3 A (only 2 channels)
4 A/4 A (only 2 channels)
6 A/6 A (only 2 channels)
Approval
CL2 Class2 (only for 1 A,
2 A, 3 A, 4 A versions)
E UL 121201 Class I
Division II
REX12 - T A 1 - 1 0 7 - DC24V - 10 A - E Example 1 channel
REX12 - T A 2 - 1 0 7 - DC24V - 4A/4A-CL2-E Example 2 channels
Order numbering code – REX12-T
Approvals/Standards
Approval
authority
Test standard File No Voltage ratings Current rating range
UL UL 2367,
UL 1310 NEC Class2
E306740 DC 24 V 1 ... 10 A,
1 A, 1 A, 2 A, 4 A, 1 A ... 4 A
UL UL 121201
CSA C22.2 No. 213
(Class I, Division 2, Groups A, B, C, D)
E320024 DC 24 V 1 ... 10 A
UL UL 508 listed,
CSA C22.2 No. 14
E492388 DC 24 V 1 A … 10 A
PM and EM – accessories approvals see technical data of accessories
Custom designed versions
Looking for a version you cannot find in our order numbering code?
Please get in touch. We will gladly find a solution for you.
type
REX12D Intelligent electronic circuit protector with
PT connection technology
Mounting method
T rail mounting
Design
E 1 Load output terminal per channel, adjustable current
ratings xA/xA, adjustable standard and COM-Mode
Number of channels
2 2 channels
Version
1 without physical isolation
Signal input
0 without signal input
Signal output
0 without signal output
Operating voltage
DC 24 V Current rating DC 24 V
Current ratings
1 A– 1 A (only 2 channels)
1 A- 1 A (only 2 channels)
Approvals
CL2 Class2 (only for
1 A - 4 A version)
E UL 121201 Class I
Division II
REX12D-T E 2 - 1 0 0 - DC24V- 1 A-10 A CL2- E ordering example
Order numbering code – REX12D-TE2
Preferred types Short description Preferred current rating (A)
REX12-TA1-E 1-channel 2 4 6 10 2/2 4/4 6/6
REX12-TA1-107-DC24V-
x x x x
REX12-TA2-E 2-channel 2 4 6 10 2/2 4/4 6/6
REX12-TA2-107-DC24V-
x x x
REX12D-TE2-E
2-channel,
adjustable
1A-10
REX12D-TE2-100-DC24V-
x
Preferred types
Preferred types described briefly
Preferred types are E-T-A products most frequently used by E-T-A
customers. We produce our preferred types in very high quantities. At
the same time, our preferred types have shorter delivery times than
other versions.
