E-XTEQ DCBS GM - Page 2

Reserved for
Serial Number Scker
AR_DCBS_UPDATE_OPTIMUS_V4.1
TECH SUPPORT - USA
1-877-453-3265
English
support.usa@e-xteq.com
HOURS OF OPERATION (EST)
Monday - Friday: 8 am - 8 pm
Comprehensive support also available
through www.e-xteq.com
CONTACT US
IR THERMOMETER
CONNECTION TO
TROLLEY
BATTERY STATUS
DIAGNOSTIC/CHARGE
INDICATOR
TROLLEY CONNECTION
INDICATOR
ERROR MODE INDICATOR
LOAD TEST INDICATOR
START TEST
CANCEL, PREVIOUS STEP
OK, NEXT STEP
ARROWS - UP,
DOWN, LEFT, RIGHT
POWER ON/OFF
GM DCBS Remote
ETHERNET PORT FOR
PHYSICAL CONNECTION
REMOTE CLAMP
CONNECTION PORT
REMOTE CONNECTION
VOLTAGE DISPLAY
TROLLEY CONNECTION
VOLTAGE DISPLAY
13
13
14
15
16
14
15
16
