Display PPI:4102 1280*960
5.8G MODE RSSI Signal Auto search racer-8
Dual True Diversity 5.3~6.0Ghz Four Antenna
HDMI IN PC\Xbox\STB CEC Control DSP audio algorithm
Vision Focal length IPD Astigmatic lens
AV IN / AV out Aspect Ratio
Update Firmware
Wide Voltage Input Power button 18650 BAT Case USB power supply
Built-in DVR H.264, 30fps Record/Playback
Diagram
OSD Display
RSSI Signal
Indicates RSSI signal for left and right RX modules. L stands for left, R stands for right (the RX modules
are printed with L or R stickers). There are two antenna plugs on the RX modules of left and right side.
Each of the sides have blue and red LED, used to distinguish 1# and 2# antennas. Green bars stand
for antenna signal strength. Red X indicates no antenna signal inputs. If using a third party RX module,
the RSSI function will not be available.
Defogging Fan Icon
If it appears on the display in green color, indicating defogging fans is activated. Otherwise, it is
