Eachine EV300D User Manual

scale 0 -1 -2 -3 -4 -5
Diopter 0
myopia
100
myopia
200
myopia
300
myopia
400
myopia
500
scale -6 -7 -8 +1 +2 +3
Diopter
myopia
600
myopia
700
myopia
800
hyperopia
100
hyperopia
200
hyperopia
300
IPD adjustment
Independent control for both sides, adjust the range of 56 ~ 72mm,wide-range IPD, suits more pilots.
Move the slider to adjust IPD. (+) means to increase IPD,(-)means to decrease IPD.
Eyeglass Frames
Using fitted eyeglasses, Astigmatism / Myopia / Hyperopia (Diopter lens not include)
AV IN / AV out
3.5mm AV connector av input av output
Support external hdmi to av input
Support external DVR
Aspect Ratio
Selectable Aspect Ratio providing different viewing experience. PICTURE Aspect Ratio
Auto 16:9 4:3 zoom1 zoom2
Just Scan(only HDMI) panorama(Default display) Point To Point(only HDMI)
Diagram
18650 BATTERY CASE
Mode /Menu /Volume Turn on/off OSD Control Channel/Band Selection
Power on/off turn on/off defog fan DVR Menu HDMI CEC Control
Cooling fan
3.5mm Headphone jack Micro USB
DC Port
MiniHDMI Port 3.5mm AV Port Defog Fan
IPD/Focal length adjustment TF slot
Eyeglass Frames(Diopter lens not include)
Product Specifications
Frequency: 5.8GHZ
Frequency range: 5333—5945 M Hz
Receiver Sensitivity: ≤-93DB
Antenna impedance: 50Ω Audio and video: AV in/out Video format: NTSC/PAL
Brightness: Adjustable Contrast: Adjustable
Pupil Distance adjusting: 56-72mm
Focal length adjusting:Under 800 degree of myopia and Hyperopia 300 degrees
Eyeglass frames:astigmatism/ myopia/hyperopia(Diopter lens not include)
Power input: 7.4V
Minimum voltage: 6.8V
Operating temperature:-9°C ~ 39°C
