1. IR Receiver Window 2.VFD Screen 3. stand by Switch
Interface Description:
No. Item Description
1 IR Receiver Receive the signal from remote control.
2 VFD Screen
display the playback status and progress and other
information for the operation.
3
Stand by Switch& work
indicator
Press the bottom to enter into standby mode;
The LED indicate shows green when turned on, and
shows red when standby.
3.3 Back View
1. Colling Fan 2.eSATA 3.DC-IN 4.Coaxial/Optical Fiber 5.HDMI Out 6.YPbPr
Out 7.AV Out 8.LAN/USB HOST 9.USB 3.0 Interface
Interface Description:
No. Item Description
