EarthQuake 6014V CRT User Manual

OPERATOR INSTRUCTIONS AND PARTS
CRT Models 6014V
Page 26
GetEarthquake.com
800-345-6007
CRT WHEEL & TILLER SHAFT PARTS & PARTS LIST
REF. NO. PART # DESCRIPTION QTY.
1 1500P101 BOLT, M6 X 25MM 6
2 1500P102 COVER, REAR TRANSMISSION 1
3 1500P103 GASKET, FRONT & REAR
TRANSMISSION COVER
2
4 1500P104 SHIM, DRIVE SHAFT 6
5 1500P105 BEARING, TAPPERED ROLLER 2
6 1500P606 SHAFT, DRIVE CRT 1
7 1500P107 BUSHING, TINE & WHEEL SHAFT 4
8 1500P108 SHIM, TINE & WHEEL SHAFT 8
9 1500P109 RING, RETAINER INTERNAL 4
10 1500P110 SEAL, GREASE TINE & WHEEL
SHAFT
4
12 1500P512 GEAR, WORM TINE CRT 1
REF. NO. PART # DESCRIPTION QTY.
13 1500P113 KEY, WOODRUFF 2
14 1500P114 SHAFT, TINE 1
15 1500P615 HOUSING, TRANSMISSION 1
16 1500P116 RING, RETAINER EXTERNAL 2
17 1500P517 GEAR, WORM WHEEL CRT 1
18 1500P618 SHAFT, WHEEL 1
19 1500P119 COVER, FRONT
TRANSMISSION
1
20 1500P120 SEAL, GREASE INPUT 1
