Operator's Manual
Original Operating Instructions
VERSA Compact Tiller
and Cultivator
P/N: 24812
ECN: 11424
REV2: 12/01/16
© 2016 Ardisam, Inc.
All Rights Reserved
Get parts online at
www.GetEarthquake.com
CAUTION ICON R1
READ OM ICON R1
Includes Models:
20015*
22662
25780*
*Model shown
SN

Questions and Answers

  • T
    Timothy HoltAug 14, 2025
    What to do if EarthQuake Tiller engine will not start?
    • K
      Kimberly EscobarAug 14, 2025
      If your EarthQuake Tiller engine won't start, try the following: * Add gas to the gas tank. * Connect the spark plug wire to the spark plug. * Ensure the ON/OFF switch is turned ON, and the engine is choked for a cold start.
  • M
    mbowenAug 17, 2025
    Why does my EarthQuake VERSA 20015 Tiller engine miss or lack power?
    • M
      Michael MartinAug 17, 2025
      Your EarthQuake Tiller engine may be missing or lacking power due to several reasons. You can try the following: * Raise the drag stake for shallower tilling. * Clean or replace the air cleaner. * Replace the spark plug and adjust the gap. * Drain and refill the gas tank with fresh gasoline. If the issue persists, the carburetor adjustment may be improper, and you should take it to an authorized engine service center.
  • M
    Michele FullerAug 20, 2025
    Why is my EarthQuake VERSA 20015 engine hard to start?
    • C
      christinelewisAug 20, 2025
      If your EarthQuake Tiller engine is hard to start, consider these solutions: 1. Drain the old fuel and replace it with fresh fuel. Use a gas stabilizer at the end of the season. 2. Make sure the spark plug wire is securely attached to the spark plug. 3. Ensure the drive safety control lever is released to neutral to start the engine.
  • D
    Dana AllenAug 25, 2025
    What to do if EarthQuake VERSA 20015 engine runs rough, floods during operation?
    • E
      Elizabeth YoungAug 25, 2025
      If your EarthQuake Tiller engine runs rough and floods during operation, clean or replace the air cleaner.
  • W
    wharrisAug 27, 2025
    Why do belts squeal in forward operation of EarthQuake VERSA 20015?
    • B
      Barbara HayesAug 27, 2025
      If the belts squeal during forward operation of your EarthQuake Tiller, you can try the following: * Adjust the belt tension with the engagement cable. * Replace the drive belt.
  • J
    jenniferrodriguezAug 30, 2025
    What to do if my EarthQuake Tiller is difficult to control when tilling?
    • M
      Mr. Peter JohnsonAug 30, 2025
      If your EarthQuake Tiller is difficult to control while tilling (machine jumps or lurches forward), try the following: * Lower the engine speed in hard ground. * Lower the drag stake for greater resistance and control of the tiller.
  • J
    Jeffrey SmithSep 2, 2025
    Why does my EarthQuake Tiller move forward during starting?
    • A
      Andrea PageSep 2, 2025
      If your EarthQuake Tiller moves forward during starting, make sure that the drive safety control lever must be released to neutral to start the engine. Also, check the belt tension.
  • S
    Sandra GibsonSep 6, 2025
    What causes excessive heat in transmission/tine area during tilling with EarthQuake VERSA 20015 Tiller?
    • D
      deborahstewartSep 6, 2025
      If you notice excessive heat build-up in the transmission/tine area of your EarthQuake Tiller during tilling, try the following: * Remove any vegetation that may be causing obstruction. * Check the transmission lubrication and add more if needed.
  • K
    kfrederickSep 10, 2025
    What causes constant buzzing sound in EarthQuake Tiller?
    • N
      Noah SinghSep 10, 2025
      If you hear a constant buzzing sound while the drive safety control lever is compressed on your EarthQuake Tiller, the following steps may help: * Properly space the wire guide from the idler pulley to clear the belt when engaged. * Adjust the engagement cable. * The belt may be stretched and needs to be replaced.
