Page #1 background image

ENGLISH

Owner’s Manual

VICTORY

Rear-Tine Tiller

Model #’s: 29409 / 29702

GAS/OIL

RATIO

50:1

Get parts or technical assistance online at

www.GetEarthquake.com or call (800) 345-6007

© 2018 Ardisam

All Rights Reserved

P/N: 32440

REV 2: 10/30/2018

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.

SERIAL NO.

DATE OF PURCHASE:

Table of Contents

Questions and Answers:

M
Megan KeithAug 12, 2025
Why does my EarthQuake VICTORY 29702 Tiller engine miss or lack power?
- H
  Heather NovakAug 12, 2025
  If your EarthQuake Tiller engine misses or lacks power, try the following: * Raise the tines for shallow tilling by lowering the depth regulator lever. * Remove and clean the fuel tank. * Clean or replace the air cleaner. * Replace the spark plug and adjust the gap. * Drain and refill the gas tank and carburetor. If the issue persists and you suspect improper carburetor adjustment, take it to an authorized engine service center.
K
Kevin RodriguezAug 16, 2025
What to do if my EarthQuake VICTORY 29702 is hard to start?
- C
  Christopher MoyerAug 16, 2025
  If your EarthQuake Tiller engine is hard to start, try these solutions: * Drain the old fuel and replace it with fresh fuel. Use a gas stabilizer at the end of the season. * Ensure the spark plug wire is securely attached to the spark plug. * Make sure the drive safety control levers are released to the neutral position to start the engine.
S
steeletraceyAug 19, 2025
What to do if tines turn, but wheels do not turn on EarthQuake Tiller?
- A
  Alisha SmithAug 19, 2025
  If the tines turn but the wheels don't on your EarthQuake Tiller, the solution is to lock the wheels in the tilling position. If the problem persists, it could be an internal transmission failure; in that case, consult your dealer.
D
David WatsonAug 23, 2025
What to do if tines turn, wheels turn, but EarthQuake VICTORY 29702 Tiller does not move?
- M
  Miguel ThomasAug 23, 2025
  If the tines turn, the wheels turn, but the EarthQuake Tiller doesn't move, try these solutions: * Raise the tines for shallower tilling by lowering the depth regulator lever. * Lift slightly on the handlebars to allow the wheels to gain traction.
E
Elizabeth BarreraAug 27, 2025
Why do belts squeal in neutral on EarthQuake VICTORY 29702 Tiller?
- S
  Sandra AndersonAug 27, 2025
  If belts squeal in neutral on your EarthQuake Tiller, follow these steps: * Adjust the forward belt guide. * Turn the engine off and allow the muffler to cool. * Disconnect the spark plug wire and secure it away from the spark plug. * Remove the belt guard. * Pull down on the drive safety control lever. * Manually bend the forward belt guide so there is 1/16 inch or less clearance between the belt guide and the belt. * Replace the belt guard and spark plug wire.
O
Omar WestAug 30, 2025
Why is my EarthQuake Tiller difficult to control?
- C
  Christopher HendersonAug 31, 2025
  If your EarthQuake Tiller is difficult to control when tilling, causing it to jump or lurch forward, try these solutions: * Lock the wheels in the tilling position. * Raise the tines for shallower tilling by lowering the depth regulator lever.
J
Juan RyanSep 3, 2025
Why does EarthQuake Tiller move forward during starting?
- J
  Joseph StephensSep 3, 2025
  If your EarthQuake Tiller moves forward during starting, ensure that the drive safety control levers are released to the neutral position to start the engine.
D
Deborah HuntSep 7, 2025
Why is there excessive heat in my EarthQuake Tiller transmission?
- M
  Mark MartinSep 7, 2025
  If you notice excessive heat build-up in the transmission or tine area of your EarthQuake Tiller during tilling, take the following steps: * Remove vegetation by following the instructions in the 'Clean Tine Axle Shaft' section of the Normal Care guide. * Check the transmission fluid and fill it if needed.

EarthQuake VICTORY 29702 Specifications

General

Brand	EarthQuake
Model	VICTORY 29702
Category	Tiller
Language	English

Summary

Warnings and Safety Precautions

Before Operating Equipment

Instructions to read and understand the manual before attempting to operate the tiller.

Intended Use and Foreseeable Misuse

Defines the tiller's intended purpose and potential misuse scenarios.

General Safety Rules

Engine Safety Precautions

Preventing Carbon Monoxide Poisoning

Crucial advice on operating the engine outdoors to avoid dangerous carbon monoxide buildup.

Operation

Controls Overview

Maintenance and Storage

Unpacking and Assembly

Tiller Assembly Steps

Operation Details

Operational Adjustments

Start-Up and Operating Procedures

Starting the Engine

Detailed steps for starting the engine, including cold and warm starts.

Tilling Operation

Guidance on how to operate the tiller for effective tilling and cultivating.

Maintenance Schedule

Servicing the Rototiller

Belt Maintenance and Replacement

Engine Maintenance

Troubleshooting and Repair

Troubleshooting Guide

Common problems, their causes, and recommended solutions for the tiller.
