Operator's Manual
VECTOR™ Compact Tiller
ITEM # PART # DESCRIPTION QT Y.
1 18004 WELDMENT VECTOR FRAME 1
2 13366 LOCK PIN WIRE BALE 1
3 92776 BOLT M6 X 1.0 X 20 HHCS GR8.8 ZN 2
4 18010 HANDLEBAR LOWER STRAP 1
5
W1265V0904
BOLT M8 X 1.25 X 20 HHCS ZN GR8.8 2
6 3245 WASHER M8 8.4MM X 24MM X 2.2MM
ZN
2
7 3252 NUT M8 X 1.25 H GR8.8 ZN 4
8
W1265V0913
NUT M6 X 1.0 HNYLK GR8.8 ZN 10
9 3247 BOLT M8 X 1.25 X 45 HHFCS GR8.8 ZN 2
10 400024 WASHER FLAT M8 8.4 X 16 X 1.6 THK
GR8.8 ZN
2
11 W1200117 WASHER M6 X 13 X 1.75 FLAT ZN 6
12 18123 WELDMENT GUARD PULLEY LOWER 1
13 18103 BOLT M6 X 1.0 X 40 HH GR 8.8 ZN 4
14 331052 NUT M12 X 1.75 HH NYLCK GR8.8 ZN 2
15 W1200116 WASHER M6 X 1.5 SPRLCK ZN 2
16 18119 WELDMENT SHIELD TINE MIDDLE 1
17 10513 BOLT M12 X 1.5 X 96 HH SHLDR M15.7
X 42
2
18 18118 WELDMENT SHIELD TINE RIGHT 1
19 18131 ASSEMBLY DRAG STAKE 1
20 18116 WELDMENT SHIELD TINE LEFT 1
21 18058 BOLT M6 x 1.0 x 12 SBHCS GR8.8 ZN 6
22 10517 WASHER 16MM ID X 25MM OD X 2.5
THK ZN
2
23 15856 WHEEL 8ID X 5/8ID IN RUBBER GRY 2
ILLUSTRATED PARTS BREAKDOWN 
Chassis Assembly
