5.2.2 Panel’s operating guideline
For Eco mode, It works with only heat pump.
For Fast mode, it work with both heat pump and E heater under any conidtion.
By controller, use can select Max.75ºC temperature(This is default limitiation, that we can make judgement
inside factory). With heat pump only, max. water out temperature is 68ºC. With both heat pump+ E heater, it
can be read the selected max. temperature.
button, the unit will switch on.
" button, the unit will switch off.
Switch on: When the unit in off state, if the user presses the
Switch off: When the unit in on state, if the user presses the
2. Checking and setting temperature
Under the main interface, the user can press the
or button to see the set temperature, the set temperature will
display and flash. The set temperature can be adjusted by pressing the
or button and automatically saved. It will
back to the main interface if 5 seconds without any operation. Or press the
button to exit the temperature setting.
3. Working mode setting
The user can switch the modes between AUTO, ECO, FAST, and MULT by pressing the
button.
4. Time setting
Press the
button to enter the time setting, hour and minute will flash，Press the or button to adjust the
corresponding year (the initial value is 2000) setting；then press the
button to set the month, hour will flash, press
the or
button to set the month (the initial value is 00)；Then press the button to set the date, and the
minute will flash. Press the
button to set the date (the initial value is 00)；Then press theor button to set the
hour, the hour will flash, press the
/ button to set the hour (the initial value is 00)；Then press the button to
set the minute, and the minute will flash. Press the
and button to set the minute (the initial value is 00). After
1. Switch on/off operation
