EAS Electric ECRTH2 - Installation Cautions for Water Entry; Preventing Water Entry During Wiring

Wall hole and wiring hole
Diameter Φ8--Φ10
Putty
Trap
Putty
Trap
Putty
Trap
44mm
Electricianbox
Wiring
hole
60mm
B C
Avoid the water enter into the wired remote controller, use trap and putty to
seal the connectors of wires during wiring installation.
45
V.1
