1(PLC: 40002) Setting the mode
Bit8-Bit15 Water temperature T1s is corresponding to the floor heating.(zone 2)
Bit0-Bit7 Water temperature T1s is corresponding to the floor heating.(zone 1)
3(PLC: 40004) Setting air temperature Ts
4(PLC: 40005) T5s
BIT15 Reserved
BIT14 Reserved
BIT13 1: climate curve setting is valid; 0: climate curve setting is invalid. (zone2)
BIT12 1: climate curve setting is valid; 0: climate curve setting is invalid. (zone1)
BIT11 DHW pump's running constant-temperature water recycling
BIT10 ECO mode
BIT9 Reserved
BIT8 Holiday home (the status can only be read, not changed)
BIT7 0: Silent mode level1; 1: Silent mode level2
BIT6 Silent mode
BIT5 Holiday away (the status can only be read, but cannot be changed)
BIT4 Disinfect
BIT3 Reserved
BIT2 Reserved
BIT1 Reserved
BIT0 Reserved
Bit8-Bit15 Climate Curve 1-9(zone 2)
Bit0-Bit7 Climate Curve 1-9(zone 1)
7(PLC: 40008) Forced water heating
8 (PLC: 40009) Forced TBH
9(PLC: 40010) Forced IBH1
10(PLC: 40011) t_SG_MAX
The room temperature range is between 17°C and 30°C, and is valid when there is Ta.
Portocol value=actual value*2
The water tank temperature range is between 20°C and 65°C.
5(PLC: 40006) Function Setting
6 (PLC: 40007) Curve selection
0: Invalid
1: Forced
on
2: Forced
off
TBH is the electric water tank heater.
IBH1 and 2 are the hydraulic module's rear electric heater.
IBH1 and 2 can be activated together.
TBH cannot be activated together with IBH1 and IBH2.
1: Auto; 2: Cool; 3: Heat; Others: Invalid
2(PLC: 40003)
Setting water water
temperature T1S
0-24 Hours
11(PLC: 40012)
T1S
12(PLC: 40013) T1S
Water temperature T1S is corresponding to the floor heating.(zone 1)
Water temperature T1S is corresponding to the floor heating.(zone 2)
13(PLC: 40014) t_ANTILOCK Default setting: 5, range: 0~60 S(Available in Sphera A)
Leaving water temperature T1s setting range instruction:
In cooling mode, T1S low temp setting range is 5~25°C;T1S high temp setting range is 18~25°C.
In heating mode, T1S low temp setting range is 22~55°C;T1S high temp setting range is 35~70°C.
