EAS Electric ECRTH2 - Unit Parameter Mapping (Cont.); Frequency, Voltage, and Temperature Parameters

53
132(PLC: 40133) Unit target frequency
133(PLC: 40134) DC bus current
134(PLC: 40135) DC bus voltage
135( PLC: 40136) TF module temperature
136(PLC: 40137)
Climate curve
T1S calculated value 1
137( PLC: 40138)
Climate curve
T1S calculated value 2
138( PLC: 40139) Water flow
139(PLC: 40140)
Limit scheme of
outdoor unit current
140(PLC: 40141)
Ability of Hyd raulic
module
141(PLC: 40142) Tsolar Tsolar
BIT1-BIT15
Respectively represent the online status
of slaves unit 1-15
BIT0
Reserved
143(PLC: 40144)
Higher bits for electricity
consumption
144(PLC: 40145)
Lower bits for electricity
consumption
145(PLC: 40146)
Higher bits for power
output
146(PLC: 40147)
Lower bits for power
output
The actual value*100, unit: kW
The corresponding calculated T1S of zone 2
The corresponding calculated T1S of zone 1
Feedback on outdoor unit, unit: °C
Hz
The actual value*100, unit: m3/H
Scheme value
142(PLC: 40143)
Quantity of units in
parallel
Unit: A
The actual value/10, unit: V
Note :
1. When Tw2 unavailable, "25" would display in upper unit address 113.
2. When T2B unavailable, the wired controller would display"--" and "25" would display in upper
unit address 113.
3.When Ta unavailable, "25" would display in upper unit address 114.
4. When E series without Tbt1Tbt2,the wired controller would display"--" and "0" would display
in upper unit addresses 120 and 121.
V.1
