Easycar E8-B - Door Lock Harness, 6-pin Connector (CN2); Door Lock System Configurations; Primary Harness (CN3)

6
INSTALLATION GUIDE
7
INSTALLATION GUIDE
USA USA
➢Door Lock Harness, 6-pin Connector (CN2)
CN2/1 BLACK (-) GROUND
CN2/ 6 PIN PLUG
AFTER MARKET DOOR LOCK SYSTEM
CN2/ 3 PIN PLUG
OEM DOOR LOCK SYSTEM
➢Primary Harness (CN3)
CN3/1 YELLOW DOOR UNLOCK OUTPUT
CN3/2 GREEN DOOR LOCK OUTPUT

N egative Door Lock System

Positive Door Lock System

Reverse Polarity System

Vacuum Door Lock System
Installation Essentiality Matters
Door Connection (CN2)

For the Vehicle
with OEM
Power Door Lock System

For the Vehicle
with After Market
Power Door Lock System
