➢Temperature Sensor (CN11): E8-B ONLY
This sensor senses the interior temperature of the vehicle. Do not mount the
sensor on the floor or the body of the vehicle.
2. Selection For Automatic and Manual
Transmission
The Jumper wire inside the cover of the main unit is used for Manual transmission
vehicles. If the unit is installed on an Automatic transmission vehicle, simply cut
the Jumper wire.
WARNING!
Do not reconnect the Jumper wire once it has been cut. It will
void all warranty and it is very unsafe.
3. Alternator Sensor
1. Dip Switch
2. Noise Sensing LED
Noisy Sensing LED
LED
The LED on the cover of the main controller unit is lit when the engine is running
and the light is turned off when the engine is off.
4. Programming
IMPORTANT!
These steps must be completed in order for the
product to operate properly.
A. Remote Control Registration
1) Press the “Start” button (OFF ACC ON) 4 times; “ON” light should be
displayed. (Parking light flash once, ready to program the remotes)
2) Press the I or button on the 1st remote.
3) Then press the I or
button on the 2nd remote.
(When the lock button is pressed on the remote, paking light flash once)
4) Remote programming is now complete.
