Easystat EA906S - Appendix 2: Table for Working Status

24
60、61、62、63、64
Shutdown fault Yes
65、66、67、68、69
BUS shorted Yes
75、76、77、78、79
Communication fault Yes
80、81、82、83、84
Relay fault Yes
85、86、87、88、89
AC input SCR fault Yes unused
90、91、92、93、94
CAN fault Yes
95、96、97、98、99
ID conflict Yes
100、101、102、103、104
Incompatible type No
Appendix 2: Table for working status
S/N Working status
LED on Front panel
Alarm beep Note
Normal Battery Bypass Fault
1 Inverter mode (mains power)
Mains power voltage ● N
Mains power
high/low voltage
protection, switch to
battery mode
● ● ★ One beep / 4 sec
2 Battery mode
Battery voltage -
normal
● ● ★ One beep / 4 sec
Warning for
abnormal voltage of
battery
● ★ ★ One beep / sec
3 Bypass mode
Mains power –
normal（under
Bypass）
● ★ One beep / 2 mins
Mains power – high
voltage warning
(under Bypass)
● ★ One beep / 4 sec
Mains power – low
voltage warning
(under Bypass)
● ★ One beep / 4 sec
4 Warning for battery disconnected
Bypass mode ● ★ One beep / 4 sec
Inverter mode ● ★ One beep / 4 sec
Power on / Switch on 6 beeps
5 Output overload protection
