Catalog data MN650002EN
Effective February 2019
Deadbreak apparatus connectors
•
Go to Step 12, page 12 to complete T-body termination.
Figure 13. Line illustration of BOL-T T-body installation.
T-body
Cable adapter
Tape marker
Concentric neutral wires
Lubricate
600 A Inter faces
Apparatus
bushing
Test point on accessible
side
7
600 A 35 kV class BOL-T connector assembly installation instructions MN650002EN February 2019
