Eaton 600 A 15 kV class push-OP Assembly/Installation Instructions

Catalog data MN650002EN
Effective February 2019
Deadbreak apparatus connectors
Table 2. Shear bolt stripback dimensions
Length
variable Measurement name Tolerance in. (mm)
Connector code S1 S3 S4 S6 S8
Allen wrench
(mm) 5 8 8 8 8
Cutbacks in (mm) in (mm) in (mm) in (mm) in (mm)
A Bushing to cable +/- ¼
(+/- 6.4)
2
(50.8)
2
(50.8)
2
(50.8)
2
(50.8)
2
(50.8)
B Jacket +/- ¼
(+/- 6.4)
13
(330.2)
13
(330.2)
13
(330.2)
13
(330.2)
13¼
(336.6)
C Insulation shield +/- 1/8
(+/- 3.2)
10½
(266.7)
10½
(266.7)
10½
(266.7)
10½
(266.7)
10½
(273.0)
D Conductor +/- 1/8
(+/- 3.2)
2¼
(57.2)
2¾
(69.9)
3¼
(82.6)
4
(101.6)
4-13/16
(122.2)
E Cable adapter check Maximum 7½
(190.5)
7½
(190.5)
7½
(190.5)
7½
(190.5)
7½
(190.5)
Table 1. Shear bolt connector
Cable conductor size Shear bolt connector
AWG or kcmil
mm2
Standard sizes
Centering ring &
color Conductor code Catalog numberCompact Compressed Concentric
1/0 1/0 1/0 25
Grey
S1 CDT630SB150
2/0 2/0 2/0 -
3/0 3/0 3/0 -
Black4/0 4/0 4/0 95
250 250 250 120
300 300 300 150 None
350 350 350 185 Black
S3 CDT630SB300500 500 500 240
None
600 550 550 300
700 600 600
400 None S4 CDT630SB400750 750 750
800 800 800
900 900 900 500
None
1000 1000 1000 -
S6 CDT1250SB630
1100 1100 1100 -
1200 1200 1200 -
1250 1250 1250 630
1300 1300 1300
800 None S8 CDT1250SB8001400 1400 1400
1500 1500 1500
3
600 A 35 kV class BOL-T connector assembly installation instructions MN650002EN February 2019
