TABLE 5-3. Function Codes (continued)
Func.
Code
Level 1
Main Menu
Level 2
Sub-Menu
Level 3
Parameter
Security Level
Factory
Setting
Key Entry Limit
Read Edit Reset Low High
32
Metering Reverse Demand 032 Reverse Load
Current Present
XXX.X A
0 NA NA NA NA NA
• This is the present value of the load current during reverse power flow, as a demand value, according to the demand time
interval at FC 46.
• The control requires source voltage from a differential or source potential transformer or from the source voltage calculation
(see FC 39) to obtain this parameter. Lack of this voltage will result in the parameter displaying dashes.
33 Metering Reverse Demand 033 Power Factor at
Max Reverse kVA
X.XX
(Date / Time shown)
0 NA NA NA NA NA
• This is the instantaneous power factor of the load at the first time the maximum kVA demand occurred (since the last reset),
during reverse power flow.
• Note: This parameter is associated with the maximum kVA demand; therefore, it cannot be reset independent of that
parameter.
• The control requires source voltage from a differential or source potential transformer or from the source voltage calculation
(see FC 39) to obtain this parameter. Lack of this voltage will result in the parameter displaying dashes.
33
Metering Reverse Demand 033 Power Factor at
Min Reverse kVA
X.XX
(Date / Time shown)
0 NA NA NA NA NA
• This is the instantaneous power factor of the load at the first time the minimum kVA demand occurred during reverse power
flow since last reset.
• Note: This parameter is associated with the minimum kVA demand; therefore, it cannot be reset independent of that
parameter.
• The control requires source voltage from a differential or source potential transformer or from the source voltage calculation
(see FC 39) to obtain this parameter. Lack of this voltage will result in the parameter displaying dashes.
34 Metering Reverse Demand 034 Reverse
kVA Load High
XXXX.X kVA
(Date / Time shown)
0 NA 1 NA NA NA
• This is the highest value of the load kVA during reverse power flow (since last reset), as a demand value, according to the
demand time interval at FC 46.
• Date and time of the occurrence of the highest kVA load is displayed.
• The control requires source voltage from a differential or source potential transformer or from the source voltage calculation
(see FC 39) to obtain this parameter. Lack of this voltage will result in the parameter displaying dashes.
34
Metering Reverse Demand 034 Reverse
kVA Load Low
XXXX.X kVA
(Date / Time shown)
0 NA 1 NA NA NA
• This is the lowest value of the load kVA during reverse power flow (since last reset), as a demand value, according to the
demand time interval at FC 46.
• Date and time of the occurrence the lowest kVA load is displayed.
• The control requires source voltage from a differential or source potential transformer or from the source voltage calculation
(see FC 39) to obtain this parameter. Lack of this voltage will result in the parameter displaying dashes.
46
CL-6 SERIES CONTROL INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225016EN January 2016
