TABLE 5-3. Function Codes (continued)
Func.
Code
Level 1
Main Menu
Level 2
Sub-Menu
Level 3
Parameter
Security Level Factory
Setting
Key Entry Limit
Read Edit Reset Low High
34
Metering Reverse Demand 034 Reverse
kVA Load Present
XXXX.X kVA
0 NA NA NA NA NA
• This is the present value of the load kVA during reverse power flow, as a demand value, according to the demand time
interval at FC 46.
• The control requires source voltage from a differential or source potential transformer or from the source voltage calculation
(see FC 39) to obtain this parameter. Lack of this voltage will result in the parameter displaying dashes.
35 Metering Reverse Demand 035 Reverse
kW Load High
XXXX.X kW
(Date / Time shown)
0 NA 1 NA NA NA
• This is the highest value of the load kW during reverse power flow (since last reset), as a demand value, according to the
demand time interval at FC 46.
• Date and time of the occurrence of the highest kW load is displayed.
• The control requires source voltage from a differential or source potential transformer or from the source voltage calculation
(see FC 39) to obtain this parameter. Lack of this voltage will result in the parameter displaying dashes.
35
Metering Reverse Demand 035 Reverse
kW Load Low
XXXX.X kW
(Date / Time shown)
0 NA 1 NA NA NA
• This is the lowest value of the load kW during reverse power flow (since last reset), as a demand value, according to the
demand time interval at FC 46.
• Date and time of the occurrence of the lowest kW load is displayed.
• The control requires source voltage from a differential or source potential transformer or from the source voltage calculation
(see FC 39) to obtain this parameter. Lack of this voltage will result in the parameter displaying dashes.
35
Metering Reverse Demand 035 Reverse
kW Load Present
XXXX.X kW
0 NA NA NA NA NA
• This is the present value of the load kW during reverse power flow, as a demand value, according to the demand time
interval at FC 46.
• The control requires source voltage from a differential or source potential transformer or from the source voltage calculation
(see FC 39) to obtain this parameter. Lack of this voltage will result in the parameter displaying dashes.
36 Metering Reverse Demand 036 Reverse
kvar Load High
XXXX.X kvar
(Date / Time shown)
0 NA 1 NA NA NA
• This is the highest value of the load kvar during reverse power flow (since last reset), as a demand value, according to the
demand time interval at FC 46.
• Date and time of the occurrence of the highest kvar load is displayed.
• The control requires source voltage from a differential or source potential transformer or from the source voltage calculation
(see FC 39) to obtain this parameter. Lack of this voltage will result in the parameter displaying dashes.
47
