TABLE 5-3. Function Codes (continued)
Func.
Code
Level 1
Main Menu
Level 2
Sub-Menu
Level 3
Parameter
Security Level
Factory
Setting
Key Entry Limit
Read Edit Reset Low High
36
Metering Reverse Demand 036 Reverse
kvar Load Low
XXXX.X kvar
(Date / Time shown)
0 NA 1 NA NA NA
• This is the lowest value of the load kvar during reverse power flow (since last reset), as a demand value, according to the
demand time interval at FC 46.
• Date and time of the occurrence of the lowest kvar load is displayed.
• The control requires source voltage from a differential or source potential transformer or from the source voltage calculation
(see FC 39) to obtain this parameter. Lack of this voltage will result in the parameter displaying dashes.
36
Metering Reverse Demand 036 Reverse kvar
Load Present
XXXX.X kvar
NA NA NA NA NA NA
• This is the present value of the load kvar during reverse power flow, as a demand value, according to the demand time
interval at FC 46.
• The control requires source voltage from a differential or source potential transformer or from the source voltage calculation
(see FC 39) to obtain this parameter. Lack of this voltage will result in the parameter displaying dashes.
37 Metering Reverse Demand 037 Reverse Source
Voltage High
XXX.X Volts
(Date / Time shown)
0 NA 1 NA NA NA
• This is the highest value of the primary input voltage of the regulator during reverse power flow (since last reset), as a
demand value, according to the demand time interval at FC 46.
• Date and time of the occurrence of the highest source voltage is displayed.
37
Metering Reverse Demand 037 Reverse Source
Voltage Low
XXX.X Volts
(Date / Time shown)
0 NA 1 NA NA NA
• This is the lowest value of the primary input voltage of the regulator during reverse power flow (since last reset), as a
demand value, according to the demand time interval at FC 46.
• Date and time of the occurrence of the lowest source voltage is displayed.
37
Metering Reverse Demand 037 Reverse Source
Voltage Present
XXX.X Volts
0 NA NA NA NA NA
• This is the present value of the primary input voltage of the regulator during reverse power flow, as a demand value,
according to the demand time interval at FC 46.
48
