TABLE 5-3. Function Codes (continued)
Func.
Code
Level 1
Main Menu
Level 2
Sub-Menu
Level 3
Parameter
Security Level Factory
Setting
Key Entry Limit
Read Edit Reset Low High
60 Features Communications 060 Com Port #1
Protocol
DNP
0 2 NA DNP NA NA
• This function defines which resident protocol of the control will be used on Com1/Com3.
• Options include:
• DNP • 2179
• See the Control Features: Digital SCADA section of this manual.
61 Features Communications 061 Com Port #1
Speed
9600
0 2 NA 9600 NA NA
• The control microprocessor has two communications channels, each with selectable baud rates.
• Options for Com1/Com3 include:
• 300 • 600 • 1200 • 2400
• 4800 • 9600 • 19200 • 38400
62 Features Communications 062 Com Port #1
Sync Time
0 mSec
0 2 NA 0 0 65535
• This defines the period of time, for Com1/Com3, the received data line must idle to assume the start of a request
message.
• See the Control Features: Digital SCADA section of this manual.
63 Features Communications 063 Com Port #1
DNP Master Adrs
1234
0 2 NA 1234 0 65535
• The control will send unsolicited responses to this master address for Com1/Com3.
64 Features Communications 064 Com Port #1
DNP Remote Adrs1
1
0 2 NA 1 0 65535
• This is the primary DNP remote address used by user.
• The DNP Remote Address 1 for Com1/Com3 is entered at FC 64.
64
Features Communications 064 Com Port #1
DNP Remote Adrs2
65519
0 2 NA 65519 0 65535
• This is the DNP remote address available for remote configuration. For more information, contact your Eaton
representative.
• The DNP Remote Address 2 for Com1/Com3 is entered at FC 64.
53
CL-6 SERIES CONTROL INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225016EN January 2016
