11 OPERATING INSTRUCTIONS MN280067EN July 2017
Type MET electronic recloser control tester operating instructions
Table 2. Quiescent drain of control accessories (control in home position), form 2 and form 3 family controls
Accessory cat. no. Description Drain (mA) Remarks
KA282ME Battery indicating milliammeter 0
KA287ME 24-VDC surge protector 0
KA293ME Load current indicating meter 0
KA304ME* Reset after reclose 2.3 For 3-sec. plug.
0.8 For10-sec. plug.
KA305ME Target-phase and ground 0
KA316ME Remote closing 0
KA319ME One time delay to lockout on ground 0
KA333ME Blocking of reclosing 0
KA336ME Target-phase and ground 0
KA339ME Dc supply adapter
48-V, 3.5-A style 6.4 48-Vdc source.
125-V, 3.5-A style 5.5 125-Vdc source.
48-V, 15-A style 9.6 48-Vdc source.
KA418ME Sequence coordination 0 If active in home.
0.8 If blocked in home.
KA472ME Lockout indicating contact 0
KA498ME Contact position indicator 0
KA522ME Remote minimum-trip doubler 0 Supervisory contacts open.
5.7 Supervisory contacts closed.
KA531ME Fuse elimination 0
KA533ME Dc supply adapter See KA339ME.
KA542ME Heater 0
KA545ME Load-current indicator 0
KA574ME Battery indicating milliammeter 0
KA577ME Instantaneous phase trip 0
KA608ME Battery indicating milliammeter 0
KA609ME Target-phase and ground 0
KA639ME Remote lockout 0
KA670ME Ground delay pickup multiplier 0 For fast operation.
11 For delayed operation.
KA674ME Ground-trip target 0
KA698ME Instantaneous ground trip 0
KA880ME Dc supply adapter
48-V, 15-A type 7.0 48-Vdc source.
125-V, 5-A type 12 125-Vdc source.
125-V, 15-A type 12 125-Vdc source.
KA896ME Ground fault target 1.4
KA1000ME Manual minimum-trip doubler 0
KA1002ME Remote minimum-trip doubler 0 Supervisory contacts open.
6 Supervisory contacts closed.
KA1004ME Remote trip 0
KA1021ME High phase and ground protection 0
KA1025ME Targets-phase only 1.3
Phase and ground 1.9
KA1030ME Targets Same as KA1025ME.
KA1036ME Instantaneous lockout-all multipliers 0.3 If phase disabled.
0 If accessory active.
0 If ground disabled.
